Flex Power Modules introduces the PKU4217D, the industry’s first DC-DC converter in the sixteenth-brick form factor that can provide output power up to 260W, at an output voltage of 10.4V. This means it is the world’s smallest converter available in the market that can deliver this level of power.
The PKU4217D is an isolated intermediate bus converter (IBC) for supplying point-of-load (PoL) regulators. It delivers market-leading power density in a compact module, making it ideal for telecoms and datacom applications that require extremely high power delivery within small footprints. For these sectors, the PKU4217D can replace existing eighth-brick converters, thus saving 40% of the space required.
The new converter has a high efficiency of typically 96.1% (at 48Vin, half load). This means it saves energy and reduces cooling requirements, thus cutting TCO. It is the industry’s first converter to use HRR technology in a sixteenth-brick module, which has increased the output power achievable by around 60W, as well as increasing efficiency compared to an eighth-brick module without HRR.
Olle Hellgren, Director of Product Management and Business Development at Flex Power Modules, said: “Using proven technology based on a patent held by Flex Power Modules, the new PKU4217D is truly at the cutting edge of power density in telecoms and datacom applications – delivering valuable space savings, without compromising on efficiency. We believe the new module will help more customers follow the industry trend of changing from 12V to 10.4V to supply PoLs, which drives further efficiencies.”
The module has an input voltage range of 36V to 60V, and provides isolation of 2250V, making it suitable for Power over Ethernet (PoE) applications. Power output is up to 25A or 260W, at 10.4Vout.
The PKU4217D is provided in an industry-standard low-profile sixteenth-brick form factor, measuring 33.02 × 22.86 × 11.30mm (1.3 × 0.9 x 0.44in). It is available optionally with a baseplate, or as a surface mounted device (SMD) version. The module meets safety requirements according to IEC/EN/UL 62368-1.
The PKU4217D is released and available in OEM quantities.
Link to the datasheet here: https://flex.com/sites/default/files/Flex%20TS_PKU4217D.pdf
