Riedon targets low cost current sensing applications with a full line up of low ohmic value resistors

by donpedro

Riedon, a specialist manufacturer of cutting-edge resistive solutions, is targeting the demanding requirements of current sensing and shunt applications with its comprehensive portfolio of low ohmic value resistors, ranging from the economical bare metal element MSR series through to its CLSA series chip resistors that provide AEC-Q200 compliance for use in harsh automotive environments. Utilizing various technologies, Riedon offers ±1% tolerance resistances from 0.5 milliohms up to 1 ohm in various package formats with TCRs as low as ±20ppm/oC and power ratings up to 5 Watts. For tolerances down to ±0.1%, Riedon is also able to supply four terminal versions of its axial lead low ohm power resistor.
Riedon’s MSR series uses a bare metal element in an all-welded construction for through-hole circuit board mounting to provide resistance values from 5mΩ to 100mΩ, while also achieving low inductance (<10nH) and low TCR (±20ppm/oC). MSR resistors are available in 1, 3 and 5-Watt power ratings with tolerances of ±1% or ±5%. Riedon
