To help satellite OEMs to streamline their system development work, as well as reducing the time and engineering effort involved, Teledyne e2v and Texas Instruments (TI) collaborated on a new radiation-tolerant DDR4 modular platform. This field-proven hardware consists of a 4GB/8GB capacity DDR4T0xG72 DDR4 memory from Teledyne e2v accompanied by a TI TPS7H3301-SP DDR termination low drop-out (LDO) voltage regulator that provides a stable supply for the DDR4 module.
Optimized for implementations where there are acute size, weight and power (SWaP) constraints to factor in, the DDR4/TPS7H3301-SP platform is very compact and convenient to use. The constituent components have already gone through comprehensive space characterization and qualification procedures to help designers achieve long-term operation without single event latch-up (SEL) and single event upset (SEU) issues arising.
This platform allows elevated levels of data storage capacity to be achieved inside a very small form factor. It requires three times less PCB area versus solutions from the competition, and its volume is smaller by a factor of ten.
Versatility is another plus point, with the DDR4T0xG72/TPS7H3301-SP modular platform being applicable across a wide range of space-grade processors (including Teledyne e2v and others), FPGAs/ACAPs (such as AMD/Xilinx, Microchip, NanoXplore, etc.) and custom-built ASICs.
More information on it is available at: https://semiconductors.teledyneimaging.com/en/products/memory/space-radiation-tolerant-4gb-8gb-ddr4/
“Having access to pre-tested, easy-to-integrate hardware is of real benefit to those constructing systems for space deployment,” states Thomas Guillemain, Marketing Manager for Digital Processing Solutions at Teledyne e2v. “This joint platform results in significant value for our space customers, particularly on SWaP.”
“The DDR4T0xG72/TPS7H3301-SP solution means that space systems will now have access to a small-format module that saves critical board area and offers high power density and verified radiation hardness and reliability,” adds Mark Toth, marketing and applications engineering manager for space-grade power products at TI.
The radiation-validated TI and Teledyne e2v devices that make up this solution are featured in Alpha Data’s Versal Core development kit ADK-VA600.
