Port GmbH is expanding its CANopen driver portfolio and is now supporting the STMicroelectronics STM32H7xx family. The ARM® Cortex®-M7-based STM32H7 MCU series leverages ST’s Non-Volatile-Memory (NVM) technology to reach the industry’s highest benchmark scores for Cortex-M-based microcontrollers with up to 1327 DMIPS/ 3224 CoreMark executing from embedded Flash memory.
port´s CANopen driver supports CAN Multiline, so that several CAN channels can be operated simultaneously. 11+ and 29bit IDs are also supported. The Keil ARMCC v5.26 was used as compiler. The Nucleo-H743ZI EVAL Board was used as the development environment
Together with the CANopen stacks from port, both the master / slave version or just the slave version can be used.
For easier integration of the CANopen library in connection with the CANopen driver “STMicroelectronics STM32H7xx family”, the version of the next Generation Port Design Tool – also called Industrial Communication Creator in the future – is available.
The CANopen Design Tool is a tool for the fast and cost-saving development of CANopen applications (devices). It generates an object dictionary and an initialization function in C code, an electronic data sheet and the documentation of the project with just a few mouse clicks. It is also used to configure the CANopen Library and the CANopen Driver Packages.
